HD Slim Front service LED Screen

Home » Product » HD Slim Front service LED Screen

Front service HD LED Video Wall

Category: Accessories

Pixel Pitch	0.93mm	1.25mm	1.56mm	1.875mm
Physical Density	1137778/㎡	640000/㎡	409600/㎡	284444/㎡
LED Shape	Mini 4 in 1	SMD1010	SMD1010	SMD1010
LED Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B
Drive Mode	1/30 Scan	1/45 Scan	1/27 Scan	1/45 Scan
Cabinet Size	600x337.5x48mm	600x337.5x48mm	600x337.5x48mm	600x337.5x48mm
Cabinet Resolution	640x360	480x270	384x216	320x180
Cabinet Weight	7kg/pc	7kg/pc	7kg/pc	7kg/pc
Brightness	≥600cd/㎡	≥600cd/㎡	≥600cd/㎡	≥600cd/㎡
Contrast	≥8000:1	≥8000:1	≥8000:1	≥8000:1
Viewing angle(H/V)	170°/170°	170°/170°	170°/170°	170°/170°
View Distance	≥1m	≥1.2m	≥1.5m	≥1.8m
Gray Scale	16bits	16bits	16bits	16bits
Color Capacity	281 trillion	281 trillion	281 trillion	281 trillion
Maximum Power	100 W/PC	100 W/PC	100 W/PC	100 W/PC
Average Power	40 W/PC	40 W/PC	40 W/PC	40 W/PC
Input voltage	110 / 220V	110 / 220V	110 / 220V	110 / 220V
Refresh Rate	≥3840Hz	≥3840Hz	≥3840Hz	≥3840Hz
Working Temperature	(-20℃～+50℃)	(-20℃～+50℃)	(-20℃～+50℃)	(-20℃～+50℃)
Operating Humidity	10-90% RH	10-90% RH	10-90% RH	10-90% RH
Life Span	100,000Hours	100,000Hours	100,000Hours	100,000Hours
IP rating(Front/Rear)	IP31/IP31	IP31/IP31	IP31/IP31	IP31/IP31
Service	Front Service	Front Service	Front Service	Front Service
