| Pixel Pitch | 6.25mm |
| Physical Density | 25600/m2 |
| LED Shape | SMD2727 |
| LED Configuration | 1R1G1B |
| Module Size | 250x250mm |
| Module Resolution | 40x40 |
| Drive Mode | 1/5 Scan |
| Cabinet Size | 500x500x72mm |
| Cabinet Resolution | 80x80 |
| Module Quantity | 4 |
| Cabinet Weight | 11kg/pc |
| Load bearing | 1000kg/m2 |
| Brightness | ≥1800cd/m2 |
| Contrast | ≥2000:1 |
| Viewing angle(H/V) | 140°/140° |
| View Distance | ≥6m |
| Gray Scale | 16bits |
| Color Capacity | 281 trillion |
| Maximum Power | 200W/PC |
| Average Power | 80W/PC |
| Input voltage | AC110 / 220V |
| Refresh Rate | ≥1920Hz |
| Working Temperature | -20℃～+50℃ |
| Operating Humidity | 10-90% RH |
| IP rating(Front/Rear) | IP65/IP65 |
| Life Span | 100,000Hours |
