Samsung panel
| Item | 46" | 46"S | 46"SS | 55" | 55"SS |
| Dimension (mm) | 1025.7×579.9×100 | 1025.7×579.9×100 | 1025.7×579.9×100 | 1215.3×686.1×120.4 | 1215.3×686.1×120.4 |
| Display Area (mm) | 1018.08×572.67 | 1018.08×572.67 | 1018.08×572.67 | 1209.6×680.4 | 1209.6×680.4 |
| Brand | Samsung panel | Samsung panel | Samsung panel | Samsung panel | Samsung panel |
| Resolution | 1920×1080 | 1366×768 | 1920×1080 | 1920×1080 | 1920×1080 |
| Color saturation | 97% | 97% | 97% | 97% | 97% |
| Brightness | 400 cd/㎡ | 450 cd/㎡ | 500 cd/㎡ | 400 cd/㎡ | 500 cd/㎡ |
| Backlight | LED | CCFL | LED | LED | LED |
| Bezel | ≤10mm | ≤6.7mm | ≤5.5mm | ≤10mm | ≤5.5mm |
| Contrast | 4000:1 | 4000:1 | 4000:1 | 4000:1 | 4000:1 |
| Field frequency | 60Hz | 60Hz | 60Hz | 60Hz | 60Hz |
| Display color | 16.7M | 16.7M | 16.7M | 16.7M | 16.7M |
| View angle | 178°/178° | 178°/178° | 178°/178° | 178°/178° | 178°/178° |
| Interface | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI |
| Control Interface | RJ45(RS232) | RJ45(RS232) | RJ45(RS232) | RJ45(RS232) | RJ45(RS232) |
| Working temperature | 0ºC~50ºC | 0ºC~50ºC | 0ºC~50ºC | 0ºC~50ºC | 0ºC~50ºC |
| Working humidity | 15-75% | 15-75% | 15-75% | 15-75% | 15-75% |
| Storage temperature | -20ºC~60ºC | -20ºC~60ºC | -20ºC~60ºC | -20ºC~60ºC | -20ºC~60ºC |
| Storage humidity | 10%~90% | 10%~90% | 10%~90% | 10%~90% | 10%~90% |
| Life | ≥100,000 Hours | ≥100,000 Hours | ≥100,000 Hours | ≥100,000 Hours | ≥100,000 Hours |
| AC Input | 110V/220V | 110V/220V | 110V/220V | 110V/220V | 110V/220V |
| Avg Power | 220W | 220W | 220W | 300W | 300W |
| Weight | 29kg/pc | 29kg/pc | 29kg/pc | 38kg/pc | 38kg/pc |
| Item | 47"SSL | 55"SL | 55"SSL |
| Dimension (mm) | 1215.3×686.1×120.4 | 1215.3×686.1×120.4 | 1213.4×684.2×120.4 |
| Display Area (mm) | 1209.6×680.4 | 1209.6×680.4 | 1209.6×680.4 |
| Brand | LG panel | LG panel | LG panel |
| Resolution | 1920×1080 | 1920×1080 | 1920×1080 |
| Color saturation | 97% | 97% | 97% |
| Brightness | 500 cd/㎡ | 500 cd/㎡ | 500 cd/㎡ |
| Backlight | LED | LED | LED |
| Bezel | ≤4.9mm | ≤5.3mm | ≤3.8mm |
| Contrast | 4000:1 | 4000:1 | 4000:1 |
| Field frequency | 60Hz | 60Hz | 60Hz |
| Display color | 16.7M | 16.7M | 16.7M |
| View angle | 178°/178° | 178°/178° | 178°/178° |
| Interface | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI | VIDEO, VGA, HDMI, DVI |
| Control Interface | RJ45(RS232) | RJ45(RS232) | RJ45(RS232) |
| Working temperature | 0ºC~50ºC | 0ºC~50ºC | 0ºC~50ºC |
| Working humidity | 15-75% | 15-75% | 15-75% |
| Storage temperature | -20ºC~60ºC | -20ºC~60ºC | -20ºC~60ºC |
| Storage humidity | 10%~90% | 10%~90% | 10%~90% |
| Life | ≥100,000 Hours | ≥100,000 Hours | ≥100,000 Hours |
| AC Input | 110V/220V | 110V/220V | 110V/220V |
| Avg Power | 300W | 300W | 300W |
| Weight | 29kg/pc | 38kg/pc | 38kg/pc |
